1DW1012 Red Jacket 1HP Submersible Dewatering Wide 230V

This item is obsolete

1 Horsepower, 230 Volts, Single Phase Submersible Dewatering Pump

The Red Jacket 1DW comes with am AISI 304 SS open impeller, casing and diffuser plate. The mechanical seal has silicon carbide sealing faces, and all metal componets are of AISI type 300 stainless steel. The motor is of air filled class F insulated design for continuous use. This pump is specifically designed for handling dirty waters, draining ditches and pits, excavating in the building trades, water transfer, and industrial water drainage or transfer.

Specifications

• Horsepower: 1
• Voltage: 230
• Phase: Single
• Maximum Amps: 6.3
• RPM: 3450
• Discharge Size: 1-1/2" NPT
• Pump Capacities: up to 110 GPM
• Total Heads: up to 66 feet TDH
• Maximum Solids: 3/8" Spherical
• Maximum Submergence: 23 feet
