Goulds PS42P1F Submersible Sewage Pump 4/10HP 230V

This item is obsolete

Goulds PS42P1F Submersible Sewage Pump 4/10HP 230V 2" Solids, 5 Amps, Piggyback Float Switch

Features

Corrosion resistant construction Cast iron body Thermoplastic impeller and cover. Upper sleeve and lower heavy duty ball bearing construction. Motor is permanently lubricated for extended service life. Powered for continuous operation. All ratings are within the working limits of the motor. Quick disconnect power cord, 10' and 20' standard lengths, heavy duty 16/3 SJTW with NEMA three prong, 230 volt grounding plug. Complete unit is heavy duty, portable and compact. Mechanical seal is carbon, ceramic, BUNA and stainless steel. Stainless steel fasteners APPLICATIONS Specially designed for the following uses: Residential sewage systems Heavy duty sump/dewatering Water transfer SPECIFICATIONS Pump - General: Discharge: 2" NPT Temperature: 104F (40C) maximum, continuous when fully submerged. Solids handling: 2" maximum sphere. Automatic models include a float switch. Manual models available.

• PS4 Pump: Maximum capacity: 110 GPM Maximum head: 23' TDH MOTOR General: Single phase 60 Hertz 230

volt Built-in thermal overload pro-tection with automatic reset. Class B insulation Oil-filled design High strength carbon steel shaft PS4 Motor: .40 HP, 3400 RPM PSC design
